详细介绍

的产品采用：广泛性APP于化工品工作，美食果汁饮料，医疗保健科研，水工作项目工程，药厂类，实验操作室，印刷类，生态学技巧，光电器件，生命安全科学性（进行和内部养育，腐熟）等领域。人体健康注谢液，血清类卸料。因为没有含邻苯二甲酸盐塑化剂，不能渗到其它的的传导液态。

食品的特点：素材：环境卫生级白金和铂金透明硅胶料工艺而成。外壁：外壁精密性强，如果没有所有的酸味，无色透明。极具非溶顽强。——无嗅、无臭,几乎无污染，包括很多塑化剂和生成剂含量。几乎符合商品FDA和生物工程医疗仪器级USP VI的标准要求。——这管往往是外面为透明体珀金混炼硅胶制品。

产品验证：——胶管依据荷兰FDA 21 CFR 177.2600(肉制品和中药菅理局)肉制品阶审核。——排水管能够华烨BfR所需要的零部件 XV标淮证书和LFBG证书。——排水管严格按照欧盟委员会标志位2008/95 / ECC的受限制动用哪些 有毒材质(RoHS)好评。

品名     PART NAME	管号     HOSE NO	内径     INNER DIA		外径     OUTER DIA		工作压力     WORK PRESSURE		爆破压力     BURST PRESSURE		弯曲半径     BEND RADIUS		真空度     VACUUM		标准长度     STANDARD LENGTH
		mm	inch	mm	inch	bar（tested at 20 degree Celsius）	psi   (tested at 68 degree Fahrenheit)	bar（tested at 20 degree Celsius）	psi   (tested at 68 degree Fahrenheit)	mm	inch	Bar	Psi	米/根     METERS PER PC
BH00-0155	#15	4.76	3/16"	7.92	0.31"	0.90	13.05	2.7	39.15	20	0.79	N/A	N/A	200
BH00-016	#16	3.18	1/8"	6.34	0.25"	1.45	21.03	4.35	63.08	30	1.18	N/A	N/A	200
BH00-017	#17	6.35	0.25"	9.60	0.36"	0.90	13.05	2.7	39.15	40	1.57	N/A	N/A	200
BH00-018	#18	7.90	0.31"	11.11	0.42"	1.00	14.50	3	43.50	60	2.36	N/A	N/A	200
BH00-024	#24	6.40	0.25"	11.40	0.42"	1.00	14.50	3	43.50	90	3.54	N/A	N/A	200
BH00-025	#25	4.80	3/16"	8.00	0.31"	2.40	34.80	7.2	104.40	110	4.33	N/A	N/A	200
BH00-026	#26	6.40	0.25"	13.00	0.52"	2.70	39.15	8.1	117.45	150	5.91	N/A	N/A	100
BH00-035	#35	7.90	0.31"	14.70	0.57"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-036	#36	9.50	0.37"	14.70	0.43"	2.70	39.15	8.1	117.45	280	11.02	N/A	N/A	100
BH00-070	#70	7.90	0.31"	18.90	0.57"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-073	#73	7.90	0.31"	16.10	0.57"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-082	#82	12.70	0.50"	19.30	0.75"	2.70	39.15	8.1	117.45	200	7.87	N/A	N/A	100
BH00-087	#87	12.70	0.50"	25.30	1.00"	2.40	34.80	7.2	104.40	200	7.87	N/A	N/A	100
BH00-088	#88	12.70	0.50"	22.20	1.00"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-088	#89	15.90	0.62"	22.20	0.87"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-091	#91	19.05	0.75	32.60	1.25"	2.40	34.80	7.2	104.40	350	13.78	N/A	N/A	100

Product application:Widely used in chemical materials treatment, food and beverage, medical research, water treatment projects, pharmaceutical, laboratory, printing, biological technology, semiconductor, Life sciences (tissue and cell culture, fermentation), etc.also used for human injection and serum delivery. The hose does not contain adjacent benzene two formate plasticizer and the transmission fluid will not penetrate.

Product description:-used in liquid and semi fluid food of medicine and cosmetic products, bio engineering.-Standard length is 20 meters per roll, and we can also to produce the specified size and length according to customer requirements.Our hose products has passed the certification of the United States FDA grade and Class VI USP and German BFR.

Product characteristics:Material:Sanitary grade platinum silicone materials.Surface: high accuracy on the surface,tasteless, colorless and Non hemolytic-odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully meet the requirements of food FDA and biological medical grade VI USP.-the outer layer of these hoses is the transparent platinum vulcanization silicone.

Quality certification:-pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.-pass the German BFR parts XV standard certification and LFBG certification.-in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.-in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
