详细介绍
物品选用：很广使用于物理品操作，食材冷饮，医药研究方案，水操作建筑项目，制药企业类，实践室，柔印，生态学技術，半导体相关行业，自己生物科学的（聚集和组织培植，发醇）等相关行业。人体组织打针液，血清类输送机。不标邻苯二甲酸盐塑化剂，不想渗进其他的的网络传输液滴。
厂品性：板材：清洁级钻石矽胶料工艺而成。外表层：外表层导致精度更高，是没有所有口感，结晶体。具有着非溶铮铮铁骨。——无嗅、无臭,是全无磷，包涵其余塑化剂和增添剂因素。是全复合肉制品FDA和海洋生物医用不锈钢级USP VI的的要求。——一些管一般 是表面层为乳白色白金塑炼硅胶材料。
茶叶品质资格认证：——连接管用USAFDA 21 CFR 177.2600(肉制品和性药物处理局)肉制官阶认正。——塑料软管能够法国BfR配件 XV条件v证书和LFBGv证书。——高压软管遵循欧盟委员会信息2008/95 / ECC的局限食用某种有影响成分(RoHS)认可的。——高压软管复合ISO10993,NSF51和荷兰药典3.1.9的规定。Product application:Widely used in chemical materials treatment, food and beverage, medical research, water treatment projects, pharmaceutical, laboratory, printing, biological technology, semiconductor, Life sciences (tissue and cell culture, fermentation), etc.also used for human injection and serum delivery. The hose does not contain adjacent benzene two formate plasticizer and the transmission fluid will not penetrate.
Product description:-used in liquid and semi fluid food of medicine and cosmetic products, bio engineering.-Standard length is 20 meters per roll, and we can also to produce the specified size and length according to customer requirements.Our hose products has passed the certification of the United States FDA grade and Class VI USP and German BFR.
Product characteristics:Material:Sanitary grade platinum silicone materials.Surface: high accuracy on the surface,tasteless, colorless and Non hemolytic-odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully meet the requirements of food FDA and biological medical grade VI USP.-the outer layer of these hoses is the transparent platinum vulcanization silicone.
Quality certification:-pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.-pass the German BFR parts XV standard certification and LFBG certification.-in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.-in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
| 东莞市世俱杯网站入口硅胶制品有限公司 |
BH00铂金硅胶蠕动泵管
Platinum silicone hose (pump hose) BH00 |
|
品名
PART NAME | 管号
HOSE NO | 内径
INNER DIA | 外径
OUTER DIA | 弯曲半径
BEND RADIUS | 真空度
VACUUM | 标准长度
STANDARD LENGTH |
| mm | inch | mm | inch | mm | inch | Bar | Psi | 米/根
METERS PER PC |
| BH00-015 | #15 | 4.76 | 3/16" | 7.92 | 0.31" | 20 | 0.79 | N/A | N/A | 15 |
| BH00-016 | #16 | 3.18 | 1/8" | 6.34 | 0.25" | 30 | 1.18 | N/A | N/A | 15 |
| BH00-017 | #17 | 6.35 | 0.25" | 9.60 | 0.36" | 40 | 1.57 | N/A | N/A | 15 |
| BH00-018 | #18 | 7.90 | 0.31" | 11.11 | 0.42" | 60 | 2.36 | N/A | N/A | 15 |
| BH00-024 | #24 | 6.40 | 0.25" | 11.40 | 0.42" | 90 | 3.54 | N/A | N/A | 15 |
| BH00-025 | #25 | 4.80 | 3/16" | 8.00 | 0.31" | 110 | 4.33 | N/A | N/A | 15 |
| BH00-026 | #26 | 6.40 | 0.25" | 13.00 | 0.52" | 150 | 5.91 | N/A | N/A | 15 |
| BH00-035 | #35 | 7.90 | 0.31" | 14.70 | 0.57" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-036 | #36 | 9.50 | 0.37" | 14.70 | 0.43" | 280 | 11.02 | N/A | N/A | 15 |
| BH00-070 | #70 | 7.90 | 0.31" | 18.90 | 0.57" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-073 | #73 | 7.90 | 0.31" | 16.10 | 0.57" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-082 | #82 | 12.70 | 0.50" | 19.30 | 0.75" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-087 | #87 | 12.70 | 0.50" | 25.30 | 1.00" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-088 | #88 | 12.70 | 0.50" | 22.20 | 1.00" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-089 | #89 | 15.90 | 0.62" | 22.20 | 0.87" | 200 | 7.87 | N/A | N/A | 15 |
| BH00-091 | #91 | 19.05 | 0.75 | 32.60 | 1.25" | 350 | 13.78 | N/A | N/A | 15 |
